Ultrasonic Deburring Cleaning System

Applicable to any material and shape

Although there are differences in difficulty level, it can correspond to most basic materials such as metal, plastics, ceramics, and composite materials thereof. Also, It is applicable even if the direction of burrs is multi directional, and intersection holes at inner surface, and the like.

Reducing labor costs

From one to several tens of thousands of pieces can be processed at once or continuously. Micro burrs (micron order size) can be removed faster and surely.

Environmentally friendly

The liquid usedsage for our ultrasonic deburring cleaning machine is just water. The main consumable goods are only some filters, so you don't need to worry about the running cost. Easy to change liquid.

[Compact type]
StarBaby-DB Series

▼

[General-purpose]
PERION-DB Series

▼

[Vacuum pre-treatment type]
MARS-DB Series

▼

[Fully automatic type]
VEGA-DB Series

▼

Compact type Ultrasonic deburring and cleaning system : StarBaby-DB Series

(36 models)

 Features

This is a compact type ultrasonic deburring and cleaning machine. It deburrs by extremely strong ultrasonic radiation.
One for line, one for next to working stand, one for connecting with a robot… various uses.
It is used in many countries for medical purposes.

 Target Materials

This is the world's only ultrasonic deburring cleaning system that can remove burrs after machining and precision molding of metals, ceramics and their composite materials, as well as wash them at the same time.

 Cleaning Agent

Water, pure water, water-soluble detergent(weak alkali), water-soluble rust inhibitors, Liquid coolant, hydrocarbon solvents

General-purpose ultrasonic deburring and cleaning system : PERION-DB Series

(90 models)

 Features

This is a general purpose ultrasonic deburring cleaning system. You just close the cover and switch on and complete deburring and cleaning at the same time.
Ultra-powerful ultrasonic waves are radiated to generate countless spherical cavities (micro vacuum cores) with a diameter of 6 to 10 mm, and deburring and cleaning are performed. Burrs are collected by filters and its prevents burrs reattachment.

 Target Materials

This is the world's only ultrasonic deburring cleaning system that can remove burrs after machining and precision molding of metals, ceramics and their composite materials, as well as wash them at the same time.

 Cleaning Agent

Water, pure water, water-soluble detergent(weak alkali), water-soluble rust inhibitors, Liquid coolant, hydrocarbon solvents

General-purpose, vacuum, pre-treatment, ultrasonic deburring and cleaning system : MARS-DB Series

(90 models)

 Features

This is a general-purpose, vacuum, pre-treatment, ultrasonic deburring and cleaning system.
Before deburring, all gasses on processing object in the cleaning tank is eliminated completely by making the liquid in the tank vacuum. This system is suitable for cleaning and deburring of objects including air stayed its inside such as having blind holes and including depressed area where air remaining at. This system is equipped with a circulation filtration mechanism and a vacuum deaerator.
Ultra-powerful ultrasonic waves are radiated to generate countless spherical cavities (micro vacuum cores) with a diameter of 6 to 10 mm, and deburring and cleaning are performed.
General ultrasonic creates less than 1mm cavities(Gaseous nebula type). The cleaning energy is the cube of the cavity diameter. Burrs are removed by impact of cavities generates and disappearing.
Burrs are collected by filters and its prevents burrs reattachment.

 Target Materials

This is target for parts with extremely complicated shapes and hard to remove air.
This is the world's only ultrasonic deburring cleaning system that can remove burrs after machining and precision molding of metals, ceramics and their composite materials, as well as wash them at the same time.

 Cleaning Agent

Water, pure water, water-soluble detergent(weak alkali), water-soluble rust inhibitors, Liquid coolant, hydrocarbon solvents

General-purpose, fully automatic, ultrasonic deburring cleaning system : VEGA-DB Series  [2-tank to 9-tank type]

(over100 models)

 Features

This is general-purpose, fully automatic, ultrasonic deburring cleaning system. A line is constructed by combining pre-cleaning (degreasing), deburring (strong precision cleaning), rust prevention, and drying. Ultrasonic barrel polishing and vacuum drying can be incorporated as required.
This is a general-purpose fully automatic deburring, cleaning and drying system.
​We guarantee the quality and mass production capacity that can meet the customer's request. Technical guidance after delivery is perfect. Please introduce the best ultrasonic technology.

 Target Materials

This is the world's only full automatic ultrasonic deburring cleaning system that can remove burrs after machining and precision molding of metals, ceramics and their composite materials, as well as wash them at the same time.

 Cleaning Agent

Water, pure water, water-soluble detergent(weak alkali), water-soluble rust inhibitors, Liquid coolant, hydrocarbon solvents
