Industrial materials (Electronics, automotive related products)

Process materials, Carrier films and Protective films

Product Name
Application/Category

Structure

Features

ASPET12-Y205 series

PET12-Y205 series

Protective thin-film adhesive sheets (For resist protection during PCB production etc…)

PET12μⅿ
(ASPET12:Antistatic coating)

Acrylic Adhesive

PET Release Liner 23μm (Silicone free)

It is silicone free.
ASPET12 is coated with a conductive polymer-based antistatic agent, making it highly conductive and antistatic.
Ideal for applications such as resist protection during printed circuit board production.

PET75-Y2 series

Process materials for die-cutting various materials (films, foams), Carrier films and Protective films

Transparent PET 75μm

Acrylic Removable Adhesive

PET Release Liner 19μm

It is used as a carrier film or protective film during processing because of its excellent removability and easy peeling with light release.

PET75-H2,RB1,RC6 series

Process materials for die-cutting various materials (films, foams), Carrier films and Protective films

Transparent PET 75μm

Acrylic Removable Adhesive

PET Release Liner 19μm

Used as protective film or a carrier during production process, reliable removability and easy handling.

ASPET75-Y2 series

Anti-static.
Process materials for die-cutting various materials (films, foams), Carrier films and Protective films

Transparent PET 75μm
(Antistatic coating)

Acrylic Removable Adhesive

PET Release Liner 19μm

It is used as a carrier film or protective film during processing because of its excellent removability and easy peeling with light release.
It is coated with a conductive polymer-based antistatic agent, making it highly conductive and antistatic.
In addition, there is no humidity dependence and no bleed-out (transfer) occurs.

PET75-Si series

Process materials for die-cutting various materials (films, foams), Carrier films and Protective films

Transparent PET 75μm

Silicone Adhesive

PET Release Liner

PET75-Si series is an adhesive sheet based on a transparent polyester film and coated with a slightly adhesive type silicone adhesive.
The adhesive strength does not increase even during high-speed peeling, making it ideal for applications such as carrier films for processing

HT PET50-Si2(20)

Protective films for displays and various components

Transparent PET 50μⅿ

Silicone Adhesive

PET Release Liner 50μm

HT PET50-Si2(20)is an adhesive sheet based on a highly transparent polyester film coated with a low-adhesive silicone-based adhesive that has excellent air bleeding properties.
Suitable for protective film. It is also possible to print.

SFPET75-Y2 series

Process materials for HDD parts processing

Transparent PET 75μm

Acrylic Adhesive

PP Release Liner
(Silicone free)

SF-PET75-Y2P30 series is a silicone-free adhesive sheet with a polyester film base coated with an acrylic adhesive that is easy to peel and has high removability.

Double-sided Tapes

Product Name
Application/Category

Structure

Features

SFA-405 OS

SFA-410 OS

Double-sided tape for fixing printed materials, nameplates, emblems, and various parts
Strong adhesive tape for oil surfaces and PP(polypropylene)

PET Release Liner 23μm

Acrylic Special Adhesive

Paper Release Liner

SFA-405 OS , SFA-410 OS are substrate-free double-sided adhesive tapes for oil surfaces.
It has strong adhesive strength to PP (polypropylene), which is generally considered difficult to stick to.

TGS-115 OS

Strong double-coated adhesive tape for oil surfaces and PP(polypropylene)

PET Release Liner

Acrylic Special Adhesive

Non-Woven

Acrylic Special Adhesive

Paper Release Liner

TGS-115 OS is a double-coated adhesive tape for oil surfaces with a non-woven substrate.
It has strong adhesive strength to PP (polypropylene), which is generally considered difficult to stick to.

TY F25W series

Double-coated adhesive tape for fixing various materials such as films and parts
(10、20、30、50、80、100μｍ)

PET Release Liner 23μm

Acrylic Adhesive

Transparent PET

Acrylic Adhesive

PET Release Liner 23μm

TY-F25W series are double coated adhesive tapes with excellent adhesion properties and repelling resistance.
We have the various thickness line-up for your help.

SFA-105,110

Double-sided tape for fixing printed materials, nameplates, emblems, and various parts

PET Release Liner 23μm

Acrylic Adhesive

Paper Release Liner

SFA-105, 110 are substrate-free double-sided adhesive tapes.
Toluene-free type, suitable for VOC countermeasure applications.

SFA-205,210

Black double-sided tape for fixing printed materials, nameplates, emblems, and various parts

PET Release Liner

Acrylic Adhesive
(Black colored)

Paper Release Liner

SFA-205, 210 are substrate-free double-sided adhesive tapes.
The adhesive is a black-colored type, which provides light-shielding properties.
Toluene-free type, suitable for VOC countermeasure applications.

SFA-305SF

Silicone-free double-sided tape for fixing HDD parts

PET Release Liner 50μm (Silicone free)

Acrylic Adhesive

PET Release Liner 50μm (Silicone free)

SFA-305SF is a substrate-free double-sided adhesive tape with low outgas and silicone-free type. (Silicone-free type: Silicones are not intentionally used.)
Suitable for applications such as HDD where outgassing is a concern.

JDM115SA

Double-sided tape for fixing silicone materials such as silicone rubber and various parts

PET Release Liner

Silicone Adhesive

Transparent PET

Acrylic Adhesive

Paper Release Liner

JDM115SA is a double-coated adhesive tape consisting of silicone adhesive and acrylic adhesive with PET film carrier.
The silicone adhesive side has excellent adhesion to adherend of silicone materials.
The Acrylic adhesive side has excellent adhesion to various adherends.

T-CONDUCTION

Double-sided tape for heat dissipation of electrical and electronic components

PET Release Liner
23μ

Acrylic Adhesive
(high thermal conductivity)

PET Release Liner
38μ

T-CONDUCTION is substrate-free double-sided adhesive tape using the adhesive having high thermal conductivity.
T-CONDUCTION raise heat radiation effect by incorporating it between heating element and the heat radiation parts of various electronic parts.

Thin Single-sided Tape

Product Name
Application/Category

Structure

Features

GL series

Thin single-sided tape
For identification, parts lamination

Transparent PET

Acrylic Adhesive
(Colored)

PET Release Liner

GL Series-colored type are very visibility.

Heat-resistant Masking Adhesive Sheet

Product Name
Application/Category

Structure

Features

PET50PA3XBLUE

Heat-resistant masking adhesive sheet

Transparent PET 50μⅿ

Silicone Adhesive
(Blue coloring)

PET Release Liner

The adhesive is colored for visibility and translucent for easy positioning.
The 50μm peel-off film specification allows for use in die-cutting applications.
